- Size: 0.78
- Place of Origin: China,Japan
- Brand Name: SMCC
- Model Number: 485,490,4105,4108, 6108T,S1105,S1110
- Weight: 340.000 kg
S/ZS195-S/ZS1130柴油机技术参数表 TECHNICAL DATA OF S/ZS195-S/ZS1125 DIESEL ENGINE | |||||
型号 MODEL | ZS1100 | ZS1110 | ZS1115 | ZS1125 | ZS1130 |
形式 TYPE | 单缸卧式四冲程SINGEL CYLINDER HORIZONTAL ,4-CYCLES | ||||
燃烧系统 COMBUSTION SYSTEM | 直接喷射式燃烧室DIRECT INJECTION COMBUSTION CHAMBER | ||||
缸径×行程 BORE*STROKE（mm） | 100×115 | 110×115 | 115×115 | 120×125 | 130×120 |
排量(L) TOTAL DISPLACEMENT(L) | 0.903 | 1.09 | 1.19 | 1.473 | 1.592 |
1小时输出功率 1-H RATED OUTPUT (KW) | 12.1 | 14.6 | 16.2 | 19.8 | 22.1 |
12小时输出功率 12-HOUR RATED OUTPUT (KW) | 11.3 | 13.2 | 14.7 | 18.4 | 20.1 |
最高转速 ROTATE SPEED (R/MIN) | 2200 | ||||
油耗 SPECIFIC FULE OIL CONSUMPTION (g/kw/h) | 233 | 231 | 228 | 230 | 230 |
润滑油消耗 SPECIFIC LUBE CONSUMPTION(g/kw/h) | ≤2.04 | ≤2.0 | ≤2.0 | ≤2.04 | ≤2.04 |
最大输出扭矩 MAX TORQUE (N.M) | 58.9 | 68.8 | 76.6 | 95.7 | 107 |
最大扭矩时的转速 MAX TORQUE SPEED (N.M) | ≤1760 | ≤1800 | |||
冷却方式 COOLING SYSTEM | 蒸发式或水冷EVAPORATION/WATER | ||||
润滑系统 LUBRICATION SYSTEM | 压力泵和飞溅COMBINED PRESSURE AND SPLASHING | ||||
起动方式 STRAT METHOD | 手摇式或电启动HAND CRANKING / ELECTRIC STARTER | ||||
控制方式 GOVERNING METHOD | 定时面板GENERAL TIMING PANEL | ||||
净重 NET WEIGHT (kg) | 150 | 175 | 180 | 220 | 220 |
20集装箱装机量 QYT FOR ONE 20 CONTAINER | 96 | 96 | 96 | 96 | 96 |
